B3J-S High Pressure Mech Seal Pump (CW Thread) 4300LPM

PART #: B3J-S-B73403

Bare Shaft Water Pump, 2500L/min, Counter Clockwise Rota

$5,142.00
In Stock

The ATP B3J-S Clockwise, Mechanical Seal pump is a high pressure, Hydraulically driven, 4” x 3” Threaded water pump with a 13.5” Impeller. This pump is driven directly by an SAE C Mount, 114″ 14 teeth Splined Shaft hydraulic motor coupled to the water pump shaft via a shaft coupling. When operating at 3,000 RPM this pump is capable of 1,150 GPM at 208 PSI and is primarily use with Off-Road, larger mine tank equipment.

This pump is a direct replacement for the Berkeley model B73403.

Note: This pump does not include the hydraulic motor.



SHIPPING

Dimensions: 0.570m (w) x 0.750m (l) x 0.720m (h)
Weight: 140kg
Cubic: 0.307800000m3

(B3J-S-B73403)

SKU B3J-S-B73403
Brand Water Wise Truck Parts
Shipping Weight 140.0000kg
